HR MAX™ Heavy Duty EZ Open Soft-close 100 lb Full Extension Side Mount Ball Bearing Slides
List Price
$22.98
Stock
In stock
Only %1 left
Part
303-300
List Price
Description
HR Max = Quality backed by Lifetime warranty Full Extension Heavy Duty Soft-close slide with relaxed pull force and ease of opening Cage hold forward - Retains cage during drawer member installation Synthetic rubber hold-in detent - prevents bounce back and roll out Grade 1 ANSI/BHMA certified with 100 lb. load rating
More Information
| FEATURES |
|---|
| 1/2" side spacing |
| Non-handed trigger disconnect release |
| 1.0 mm x 1.0 mm x 1.2 mm cold rolled steel material |
| Installation brackets available |
| 6.3 mm Euro screw or #8 x 7/16" truss head screw is recommended |
| NOTES | |
|---|---|
| Full Carton Count | 10 |
| Inner Carton Count | 10 |
Details
| Item Number | 303-300 |
|---|---|
| Closing | Soft-close |
| Minimum Cabinet Depth | 0.957 |
| Cabinet Type | Faceframe or Frameless |
| ADA Friendly | No |
| Adjustable | Yes |
| Load Rating | 100 lb |
| Extension | Full Extension |
| Brand | HR Max |
| Series | 303-300 Series |
| Mount Type | Side Mount |
| Height | 45 mm |
| Width | 0.957" |
| Patent | Pending |
| Certification | ANSI/BHMA A156.9-2010 |
| Warranty Period | Limited Lifetime |
